Heaterking – Round

Wrapping up a pile of stones as the actual heater for your sauna delivers such a great steam experience! Of course you need a grid of some sort to keep the stones in place, and I didn’t want this grid to look dead boring. So I applied my “Junglefire” pattern as the stainless steel grid to keep the stones in place. A strong and visual steam provider.

Dragonfire Heaters:

Technical Data

Heater Model KW Sauna Room
min (m3) max
Control Size of heater (mm)
WIDTH DEPTH HEIGHT
Stones (kG)
w/o Stone Spacer
Stones (kG)
with Stone Spacer
DRFT2-30NS 3 2 – 4 separate 250 -250 – 1325 70 60
DRFT3-35NS 3,5 3 – 6 separate 250 -250 – 1325 70 60
DRFT3-45NS 4,5 3 – 6 separate 250 -250 – 1325 70 60
DRFT3-60NS 6 5 – 8 separate 250 -250 – 1325 70 60
DRFT4-60NS 6 5 – 9 separate 295 – 295 – 1325 105 90
DRFT5-80NS 8 7 – 13 separate 295 – 295 – 1325 105 90
DRFT5-90NS 9 8 – 14 separate 295 – 295 – 1325 105 90
DRFT6-80NS 8 7 – 14 separate 355 – 355 – 1325 160 100
DRFT6-90NS 9 8 – 15 separate 355 – 355 – 1325 160 100
DRFT6-105NS 10,5 9 – 16 separate 355 – 355 – 1325 160 100
DRFT6-120NS 12 11 – 18 separate 355 – 355 – 1325 160 100
DRFT9-105NS 10,5 10 – 16 separate 425 – 425 – 1325 230 165
DRFT9-120NS 12 11 – 20 separate 425 – 425 – 1325 230 165
DRFT9-150NS 15 14 – 25 separate 425 – 425 – 1325 230 165
DRFT9-180NS 18 18 – 28 separate 425 – 425 – 1325 230 165
DRFT12-150NS 15 15 – 26 separate 525 – 525 – 1325 360 220
DRFT12-180NS 18 18 – 30 separate 525 – 525 – 1325 360 220
DRFT12-210NS 21 22 – 35 separate 525 – 525 – 1325 360 220
DRFT12-240NS 24 24 – 40 separate 525 – 525 – 1325 360 220
