Power Range: 4.5 – 9kW

Aries Wall NS

The Aries Wall is a space-saving design with the same stylish yet minimalist aesthetic of all Tower heaters. Its size and shape ensure that it takes up less space in any sauna layout, leaving more room for bathers to bask in deeply reinvigorating sauna sessions. Its built-in stone spacer ensures shorter heating time for the sauna stones and a longer life span for the heating elements.

» Power range: 4.5 – 9.0kW

» Available control: Saunova/Innova (NS)
» Built-in stone spacer

» Adjustable legs
» Stainless steel casing

» Optional heater guard
» Optional integration collar

Inquire

Specifications

Technical Data

Heater Model	kW	Sauna Room min. (m3) max.	Size of Heater (mm) Length Width Height	Stones (kg)	Control	Minimum Safety Distances A \| B
ARI3-45NS-WL-P-C	4.5	3 – 6	250 x 415 x 1030	65	Separate	100	1900
ARI3-60NS-WL-P-C	6.0	5 – 9	250 x 415 x 1030	65	Separate	100	1900
ARI3-75NS-WL-P-C	7.5	7 – 13	250 x 415 x 1030	65	Separate	100	1900
ARI3-90NS-WL-P-C	9.0	8 – 14	250 x 415 x 1030	65	Separate	100	1900

Resources

Aries Wall NS Manual

Safety Features

Energy Efficient

Durable Contructions

Efficient Heating

User-Friendly Controls

ACCESSORIES

Wall Heater Guard

(Heater Guard Rail)

Wall Integration Collar

(Cedar/Aspen)

Wall Integration Collar

(Soapstone)

Wall Integration Collar

(Stainless Steel)

Cozy Tank

(Water volume: 0.3L)

Cozy Tank

(Water volume: 0.6L)

Sauna Stones

(Size: 20kg)

Model	Size of Guard Rail (mm)
Model	Length	Width	Height
ARI-GUARD-W3-WL-D	665	380	110
ARI-GUARD-W3-WL-A	665	380	110

Model	Size of Collar (mm)
Model	Length	Width	Height
TH-Collar-W2-WL-D \| A	345	630	45
TH-Collar-W4-WL-D \| A	385	715	45
TH-Collar-W6-WL-D \| A	425	790	45
TH-Collar-W9-WL-D \| A	480	890	45
TH-Collar-W12-WL-D \| A	545	1030	45

Model	Size of Collar (mm)
Model	Length	Width	Height
TH-COLLAR-S2-WL	345	635	45
TH-COLLA-S4-WL	390	720	45
TH-COLLA-S6-WL	425	795	45
TH-COLLA-S9-WL	475	895	45
TH-COLLA-S12-WL	545	1035	45

Model	Size of Collar (mm)
Model	Length	Width	Height
TH-COLLAR-ST2-WL	355	650	42
TH-COLLAR-ST4-WL	380	700	42
TH-COLLAR-ST6-WL	445	830	42
TH-COLLAR-ST9-WL	470	880	42
TH-COLLAR-ST12-WL	535	1010	42
